Référence : 00125363
Prix catalogue :
72,50 €
HTVA 21,00 %
| Code Intrastat | 8481-8079 |
| Poids brut (kg) | 0,33 |
| Pays d'origine | DE |
| Eclass | 37010000 |
| UNSPSC Code | 31251500 |
6014-D02,5FFMSGM81-5-024/DC-08 - 3/2-way-solenoid valve, direct acting
- 3/2 - D - normally open - inlet port 1 (P/NO) connected with outlet port 2 (B/ OUT), exhaust port 3 (R/NC) closed
- 2,50 mm (7/64 inch)
- 0,00 bar - 6,00 bar (6,00 bar)
- Brass
- Inner thread - G1/8
- 24,00 V - 24,00 V
- FKM (Fluor rubber)
- -10,00 °C - 100,00 °C
- Valve complete
- 3/2 - D - normally open - inlet port 1 (P/NO) connected with outlet port 2 (B/ OUT), exhaust port 3 (R/NC) closed
- 2,50 mm (7/64 inch)
- 0,00 bar - 6,00 bar (6,00 bar)
- Brass
- Inner thread - G1/8
- 24,00 V - 24,00 V
- FKM (Fluor rubber)
- -10,00 °C - 100,00 °C
- Valve complete
