| Supplier series | MS9 |
| Specifications | Particulate |
| Body material | Aluminum |
| Piston seal material | NBR |
| Tank material | Metal |
| Filtration | 40 µm |
| Diameter of connection | 3/4" |
| Max flow at upstream pressure | 10 bar |
| Max flow (ANR) | 8000 l/min |
| Regulation pressure | 0,3 to 4 bar |
| Max input pressure at 23°C | 12 bar |
| Set pressure | 4 bar |
| ?P load loss | 1 bar |
| Fluid working Temp | (+)5°C to (+)60°C |
| Compatibility - fluids | Air or neutral gas |
| Customs duty number | 8481-1005 |
| Gross weight (kg) | 0 |
| Eclass | 27290000 |
| Country of origin | HU |
| UNSPSC Code | 27131700 |
