Reference : CHFX.006.020
Brand reference : FIG. 250 DN020
Catalog Price :
€99.87
Tax excluded 21.00 %
| Body material | GG25 cast iron |
| Sealing | Graphite |
| Type of connection | With flanges |
| Diameter of connection | DN20 |
| GN | 16 |
| PN | 16 |
| Fluid working Temp | 0°C to (+)300°C |
| Operation | Horizontal or vertical mounting |
| Specifications | Spring check |
| Compatibility - fluids | For water, hot water, steam and compressed air |
| Customs duty number | 8481-8071 |
| Gross weight (kg) | 3,2 |
| Eclass | 37010000 |
| Country of origin | CH |
| UNSPSC Code | 40140000 |
F&M spring loaded check valve:
- Body in GG25 cast iron
- Graphite seal
- Flanged connection in DN20
- PN16
- GN16
- Operation: horizontal installation only
- Without control
- Operating temperature of the fluid: 0°C to (+)300°C
- Body in GG25 cast iron
- Graphite seal
- Flanged connection in DN20
- PN16
- GN16
- Operation: horizontal installation only
- Without control
- Operating temperature of the fluid: 0°C to (+)300°C
