| Body material | PVC-U |
| Sealing | EPDM |
| Type of connection | With flanges |
| Diameter of connection | DN80 |
| GN | 10 |
| PN | 10 |
| Fluid working Temp | (+)10°C to (+)60°C |
| Operated | Manual by handwheel |
| Specifications | Standard bore |
| Compatibility - fluids | For common compatible fluids |
| Customs duty number | 8481-8087 |
| Gross weight (kg) | 8,678 |
| Eclass | 37010000 |
| Country of origin | DE |
| UNSPSC Code | 40140000 |
