| Body material | PVC-U |
| Sealing | FPM (Viton®) |
| Type of connection | Threaded Female |
| Diameter of connection | 1'' |
| PN | 10 |
| Fluid working Temp | (+)10°C to (+)60°C |
| Operated | Manual by handwheel |
| Specifications | Standard bore |
| Compatibility - fluids | For common compatible fluids |
| Customs duty number | 8481-8087 |
| Gross weight (kg) | 0 |
| Eclass | 37010000 |
| UNSPSC Code | 40140000 |
