Reference : R69040D7R141HDN
Brand reference : 88452633
Catalog Price :
€568.39
Tax excluded 21.00 %
| Body material | PVC-U |
| Sealing | FPM (Viton®) |
| Type of connection | Threaded Female |
| Diameter of connection | 1''1/2 |
| PN | 10 |
| Control pressure | 5 to 7 bar |
| Fluid working Temp | (+)10°C to (+)60°C |
| Operated | NC single-acting air operated |
| Specifications | Standard bore |
| Compatibility - fluids | For common compatible fluids |
| Customs duty number | 8481-8087 |
| Gross weight (kg) | 0 |
| Eclass | 37010000 |
| UNSPSC Code | 40140000 |
