Reference : R69015D7141EDN
Brand reference : 88389027
Catalog Price :
€304.26
Tax excluded 21.00 %
| Body material | PVC-U |
| Sealing | FPM (Viton®) |
| Type of connection | To glue |
| Diameter of connection | DN15 |
| PN | 10 |
| Control pressure | 5 to 7 bar |
| Fluid working Temp | (+)10°C to (+)60°C |
| Operated | NC single-acting air operated |
| Specifications | Standard bore |
| Compatibility - fluids | For common compatible fluids |
| Customs duty number | 8481-8087 |
| Gross weight (kg) | 1,067 |
| Eclass | 37010000 |
| Country of origin | DE |
| UNSPSC Code | 40140000 |
