Reference : GLFP.002.025/10
Brand reference : 88296901
Catalog Price :
€581.33
Tax excluded 21.00 %
| Body material | 316 Stainless Steel |
| Sealing | PTFE |
| Type of connection | With flanges |
| Diameter of connection | DN25 |
| GN | 25 |
| PN | 10 |
| Control pressure | 5,5 to 7 bar |
| Fluid working Temp | (-)10°C to (+)180°C |
| Operated | NC single-acting air operated |
| Specifications | 2-way - Without bellows |
| Compatibility - fluids | For neutral or aggressive fluids in liquid, gas or vapor form |
| Customs duty number | 8481-8073 |
| Gross weight (kg) | 4,912 |
| Eclass | 37010000 |
| UNSPSC Code | 40140000 |
