Reference : EJFX.002.250
Catalog gross price :
€542.10
Tax excluded 21.00 %
| Body material | Steel |
| Sealing | EPDM |
| Type of connection | With flanges |
| Diameter of connection | DN250 |
| GN | 16 |
| PN | 16 |
| Fluid working Temp | (-)10°C to (+)100°C |
| Specifications | Standard model |
| Customs duty number | 4016-9952 |
| Gross weight (kg) | 23,32 |
| Eclass | 37210000 |
| Country of origin | CN |
| UNSPSC Code | 40140000 |
Rubber expansion joint
- DN250
- GN16
- PN16
- Working temperature of the fluid : - 10°C to + 100°C
- EPDM pipe and outer cover
- Nylon fabric reinforcement
- Holding ring in hardened steel
- Rotating flanges in zinc-plated steel
- Vibration and noise absorption
- Linear and angular compression
- Applications: Water supply and distribution networks, heating and air conditioning
- Available options: gap limiter
- DN250
- GN16
- PN16
- Working temperature of the fluid : - 10°C to + 100°C
- EPDM pipe and outer cover
- Nylon fabric reinforcement
- Holding ring in hardened steel
- Rotating flanges in zinc-plated steel
- Vibration and noise absorption
- Linear and angular compression
- Applications: Water supply and distribution networks, heating and air conditioning
- Available options: gap limiter
