Reference : EJFX.003.080
Catalog gross price :
€132.92
Tax excluded 21.00 %
| Body material | Steel |
| Sealing | NBR |
| Type of connection | With flanges |
| Diameter of connection | DN80 |
| GN | 10 |
| PN | 16 |
| Fluid working Temp | (-)10°C to (+)80°C |
| Specifications | Standard model |
| Customs duty number | 4016-9952 |
| Gross weight (kg) | 6,23 |
| Eclass | 37210000 |
| Country of origin | CN |
| UNSPSC Code | 40140000 |
Expansion joint :
- DN80
- GN10
- PN16
- Working temperature of the fluid : - 10°C to + 80°C
- Pipe and outer coating in NBR
- Nylon fabric reinforcement
- Retaining ring in hardened steel
- Rotating flanges in zinc-plated steel
- Vibration and noise absorption
- Linear and angular compression
- Applications: Mineral oils, hydrocarbons, fuel oil
- Available options: gap limiter
- DN80
- GN10
- PN16
- Working temperature of the fluid : - 10°C to + 80°C
- Pipe and outer coating in NBR
- Nylon fabric reinforcement
- Retaining ring in hardened steel
- Rotating flanges in zinc-plated steel
- Vibration and noise absorption
- Linear and angular compression
- Applications: Mineral oils, hydrocarbons, fuel oil
- Available options: gap limiter
