Reference : SAFX.003.032.035
Catalog Price :
€1,459.64
Tax excluded 21.00 %
| Body material | GG25 cast iron |
| Sealing | EPDM |
| Type of connection | With flanges |
| Input connection | DN32 |
| Output connection | DN40 |
| GN | 16 |
| Output GN | 10/16 |
| PN | 16 |
| Tare pressure | 3,5 bar |
| Fluid working Temp | (-)10°C to (+)120°C |
| Specifications | With closed hood |
| Compatibility - fluids | For water |
| Customs duty number | 8481-8081 |
| Gross weight (kg) | 0 |
| Eclass | 37010000 |
| UNSPSC Code | 40140000 |
