Reference : C23BB400-X
Catalog Price :
€330.73
Tax excluded 21.00 %
| Function | 5/2 Bistable |
| Operated | With pilot |
| Return | Electropneumatic |
| Standard | ISO 2 |
| Body material | Anodized aluminum peinted |
| Joints | Without |
| Voltage | Without |
| Flow at 6 bar (ANR) | 2400 |
| Operating pressure | 1 to 10 bar intern pilot - Vacuum to 21 bar external pilot |
| Control pressure | 1 to 10 bar |
| Fluid working Temp | (-)10°C to (+)60°C |
| Compatibility - fluids | Air or neutral gas, filtered, lubricated or not |
| Customs duty number | 8481-2090 |
| Gross weight (kg) | 0,494 |
| Eclass | 27220000 |
| Country of origin | PL |
| UNSPSC Code | 31251500 |
