Spool valve on subbase - 5/3 CC - Electro-pneumatic - Center spring return - No gasket

Name: Spool valve on subbase - 5/3 CC - Electro-pneumatic - Center spring return - No gasket
Brand: Asco
SKU: C12BB600-X
Price: 179.78 EUR
Availability: OutOfStock

Reference : C12BB600-X

Catalog Price :

€179.78

Tax excluded 21.00 %

Stock Belgique (Liège)	-
Stock Belgique (Hainaut)	-
Stock Luxembourg (Troisvierges)	-
Stock usine	Quantity and short lead time to be confirmed on request

Usual lead time :
11-15 working days

Function	5/3 Center closed
Operated	With pilot
Return	Spring at centre
Standard	ISO 1
Body material	Anodized aluminum peinted
Joints	Without
Flow at 6 bar (ANR)	1400
Operating pressure	1 to 10 bar intern pilot - Vacuum to 21 bar external pilot
Control pressure	1 to 10 bar
Fluid working Temp	(-)10°C to (+)60°C
Compatibility - fluids	Air or neutral gas, filtered, lubricated or not
Customs duty number	8481-2090
Gross weight (kg)	0,32754
Eclass	27220000
Country of origin	PL
UNSPSC Code	31251500
