Spool valve on subbase - 5/3 CC - Electro-pneumatic - Center spring return - No gasket

Name: Spool valve on subbase - 5/3 CC - Electro-pneumatic - Center spring return - No gasket
Brand: Asco
SKU: C34BB600-X
Price: 516.46 EUR
Availability: OutOfStock

Reference : C34BB600-X

Catalog Price :

€516.46

Tax excluded 21.00 %

Stock Luxembourg (Troisvierges)	-
Stock Belgium (Barchon)	-
Stock Belgium (Chaineux)	-
Manufacturer stock	-

Usual lead time :
11-15 working days

Function	5/3 Center closed
Operated	With pilot
Return	Spring at centre
Standard	ISO 3
Body material	Anodized aluminum peinted
Joints	Without
Voltage	Without
Flow at 6 bar (ANR)	4800
Operating pressure	1 to 10 bar intern pilot - Vacuum to 21 bar external pilot
Control pressure	1 to 10 bar
Fluid working Temp	(-)10°C to (+)60°C
Compatibility - fluids	Air or neutral gas, filtered, lubricated or not
Customs duty number	8481-2090
Gross weight (kg)	1,06102
Eclass	27220000
Country of origin	PL
UNSPSC Code	31251500
