| Customs duty number | 8421-2100 |
| Gross weight (kg) | 8,5 |
| Country of origin | CH |
| Eclass | 37010000 |
| UNSPSC Code | 40140000 |
Y strainer stainless steel with flanges FIG.385
- DN 40
- Flanged connection according to DIN EN 1092-1 PN16/40
- Maximum operating pressure 40 bar
- Body and lid in stainless steel 1.4408
- Screen in stainless steel 1.4401
- Graphite lid gasket
- Temperature range from -10°C to +400°C
- Length between flanges according to DIN EN 558-1, series 1
- Filtration threshold 0.8 mm
- Bleed port with 1/2" plug
