Butterfly valve - GGG40/EPDM/CF8M - DN150 - WAFER GN6/10/16 ANSI 150 - PN16 - Hand lever

Reference : BUWM.001.150

Brand reference : 88661913

Catalog gross price :

€317.20

Tax excluded 21.00 %

Stock Belgique (Liège)	6
Stock Belgique (Hainaut)	1
Stock Luxembourg (Troisvierges)	6
Stock usine	Quantity and short lead time to be confirmed on request

Body material	Nodular cast iron (GGG40-50)
Sealing	EPDM
Type of connection	Wafer
Diameter of connection	DN150
GN	16
PN	16
Fluid working Temp	(-)10°C to (+)120°C
Operated	Manual by notched lever
Compatibility - fluids	Pour fluides non-agressifs, eau, eau déminéralisée
Customs duty number	8481-8085
Gross weight (kg)	9,921
Eclass	37010000
UNSPSC Code	40140000

Description
Documents

Butterfly valve - GGG40/EPDM/CF8M - DN150 - WAFER GN6/10/16 ANSI 150 - PN16 - Hand lever
